30" Whirlpool Electric Ceramic Glass Cooktop With Two Dual Radiant Elements - WCE77US0HB
30" Whirlpool Electric Ceramic Glass Cooktop With Two Dual Radiant Elements - WCE77US0HB
30" Whirlpool Electric Ceramic Glass Cooktop With Two Dual Radiant Elements - WCE77US0HS
![](/img/brandlogo/32_Whirlpool.png)
Appliances to feed any family's appetite. :
Additional Features :
FlexHeat Dual Radiant Element
Get two elements in one with a 6" inner ring that's great for smaller pots and pans and a 10" expandable outer ring that makes room for larger cookware.
Easy-Wipe Ceramic Glass Cooktop
Wiping up spills is simple with the easy-to-clean cooktop.
Warm Zone Element
Keep food warm while you're finishing the rest of the meal using this low-powered element.
5 Element Cooktop
Cook more of your family's favorites and enjoy added versatility with a fifth element.
Dishwasher-Safe Knobs
Make cleanup easy by washing knobs right in the dishwasher.
Hot Surface Indicator Light
See when the cooktop's still hot to the touch, even after it's been turned off, with a light that lets you know.
Wall Oven Compatible
Install this cooktop to work with a wall oven or on its own for added flexibility.
6" Extra Element
Cook small dishes like sides and sauces on the 6" extra element.
#1 Selling Appliance Brand in the U.S.A.
Dimensions | |
---|---|
Cutout Depth Max | 20-9/16 in |
Cutout Depth Min | 20-3/8 in |
Cutout Width Max | 29-9/16 in |
Cutout Width Min | 29-1/16 in |
Depth | 21-3/4 in |
Height | 5-1/4 in |
Maximum Height | 5-1/4 in |
Net Weight | 41 lbs |
Width | 30-13/16 in |
Configuration and Overview | |
Cooktop Type | Standard |
Heating Technology | Electric |
Installs Over Built-In Oven | Yes |
LP Convertible | No |
Power Boost | No |
Size | 30 in |
CONTROLS | |
Control Location | Right |
Infinite Heat Controls | Yes |
Knob Color | Black |
Knob Type | Dishwasher-Safe Plastic |
Cooktop Details | |
Automatic Pan Detection | No |
Center Rear Element-Burner Size | 6"" |
Cooktop Configuration | All Burners |
Cooktop Element Style | Radiant |
Cooktop Surface Color | Black |
Downdraft Vent | No |
Heating Element On Indicator Light | Yes |
Hot Surface Indicator Light | Yes |
Left Front Element-Burner Power | 3000W/1900W |
Left Front Element-Burner Size | 10""/6"" |
Left Rear Element-Burner Size | 6"" |
Number of Burner | 5 |
Number of Open Bays | NA |
Right Front Element-Burner Size | 10""/6"" |
Right Front Element-Burner Type | Dual |
Right Rear Element-Burner Size | 6"" |
Appearance | |
Digital Display | No |
Electrical | |
208V Compatible | Yes |
Power Cord Included | No |
Features | |
Power Outage Compatible | No |
EndecaProps | |
ProductOutletCategories | Cooking |
Energy | |
Annual Energy Usage [kWh] | 258.0 |
DETAILS | |
Surface | Glass |
