36" DCS 5.3 Cu. Ft. Gas Range With 4 Burners And Griddle - RGV2364GDN

Category : Ranges
SKU : RGV2364GDN


Literature

For the chef who demands premium cooking performance, DCS Gas Ranges heat up rapidly and deliver precise oven temperatures. DCS cooktops have unique, patented Dual Flow Burners that let you fire up a fierce heat in an instant -- and just as quickly turn it down to a precise full surface simmer with the gentlest of flames. Cooktop burner powers reach up to an extraordinary 23,500 BTU with total surface output reaching up to 95,500 BTU. The powerful infrared broiler delivers up to 19,000 BTU and provides intense heat directly to the food -- perfect for getting a crisp surface while retaining the moisture inside.

Perfect Heat

Sealed Dual Flow Burners deliver cooktop power up to 23,500 BTU (NG models) for seriously fast boiling right down to a gentle 140°F full surface simmer. DCS Gas Range ovens heat-up very quickly and deliver precise oven temperatures, with a powerful infrared broiler delivering up to 19,000 BTUs (NG models) of intense heat -- perfect for getting a crisp surface while retaining the moisture inside.

Total Control

From the highest to the lowest temperature settings you get precise control with the halo-illuminated cooktop dials. DCS Range ovens have electronic oven control for precise and consistent oven temperatures delivering superior performance.

Easy to Clean

A continuous sealed cooktop surface coupled with a commercial-style stainless steel finish allow easy cleaning.

Information at a Glance

LED Halo control dials for information at a glance. White -- heating up; orange temperature is reached.

Cooking Flexibility

DCS Gas Range ovens have generous capacity, large enough for a family feast. The full extension telescopic racking system gives you smooth and easy access to the oven, which is large enough to hold full size baking sheets or a 20lb turkey. The cooktops unique grate design and high powered burners puts the flame where you need it and lets you boil faster or simmer gently anywhere on the cooktop. The griddle plate allows you to cook several foods at once. Heavyweight stainless steel griddles can be set to desired temperatures and then maintained evenly across the entire griddle surface.

Kitchen Family Match

Handle options -- round or square -- to suit any kitchen and designed to match the DCS professional kitchen family.

Accessories sold separately
Recommended hoodVS36 / VS1236 -36" Pro Hood
Square handle optionAH-R36
Burner ratings
Max burner power23500BTU
Power back left18500BTU
Power back right18500BTU
Power front left23500BTU
Power front right18500BTU
Power griddle16500BTU
Simmer on all burners140°F
Total cooktop power95500BTU
Burners
Dual Flow Burners4
Capacity
Main oven- Shelf positions5
Main oven- Total Capacity (AHAM)5.3cu ft
Cooking Modes
Main oven functions3
Gas Requirements
Pressure6" to 9" W.C
Measurements
Depth (excluding handle and dials)29 1/8"
Height (excluding vent trim)35 3/4 - 36 3/4"
Performance
Main oven- Bake29000BTU
Main oven- Broil19000BTU
Power Requirements
Circuit supply current15A
Supply Frequency60Hz
Supply Voltage120V
Wire3
SAFETY
Main oven- Full extention telescopic racks3
Warranty
WarrantyLimited 2 Years Parts & Labor
