48" Fisher & Paykel Series 9 Professional Gas Rangetop With 8 Burners - CPV3-488-N
You may also like
Eight burners for when you need maximum performance and cooktop space – great for those who love to cook for a crowd.
Overview
- Your burners can deliver anything from very high 23,500 BTU heat for seriously fast boiling, to the most gentle flame for simmering
- Continuous surface grates designed for pots and pans to move safely across the cooktop
- Designed to match Professional style appliances
- Made from quality materials and real stainless steel
Features and Benefits
Cooktop power
Sealed Dual Flow Burners deliver rangetop power up to 23,500 BTU for seriously fast boiling right down to a precise 140°F full surface simmer with the gentlest of flames.
Precise control
From the highest to the lowest temperatures you get total control with halo-illuminated rangetop dials. A precise full surface simmer is delivered across all burners.
Cooking flexibility
The continuous surface grates are designed for pots and pans to move safely across the rangetop. The deep-platform style grates provide full coverage so heat goes directly onto the pot, for a faster boil.
Easy to clean
These rangetops are easy to clean with sealed burners and a continuous, porcelain basepan.
Information at a glance
LED halo control dials provide information at a glance and assist in alerting you if any burners are accidentally left on.
Design quality
This rangetop is built to last with craftsmanship in every detail, featuring real stainless steel, cast-iron trivets, and titanium coated dials.
| Burner ratings | |
|---|---|
| Max burner power | 23,500 |
| Power back centre | 18,500 |
| Power back centre (2) | 18,500 |
| Power back left | 18,500 |
| Power back right | 18,500 |
| Power front centre | 18,500 |
| Power front centre (2) | 18,500 |
| Power front left | 23,500 |
| Power front right | 23,500 |
| Total Power | 158,000 |
| CONTROLS | |
| Star K Certification | Yes |
| Gas Requirements | |
| Fitting and pipe | NPT, min. ⅝ ∅ flex line |
| Supply Pressure (natural gas) | 6 to 9 W.C |
| Performance | |
| Easy clean porcelain basepan | Yes |
| Sealed Dual Flow Burners™ | 8 |
| Sealed cooking surface | Yes |
| Simmer on all burners | 140°F |
| Power Requirements | |
| Amperage | 15A |
| Supply frequency | 60Hz |
| Supply voltage | 120V |
| Product Dimensions | |
| Depth | 28 |
| Height | 8 5⁄16 |
| Width | 47 7⁄8 |
| Recommended back guards and ventilation | |
| Combustible situation | BGCV2-3048H |
| Non combustible situation | BGCV2-3048 / BGCV2-1248 |
| Pro hood | HCB48-12_N |
| Warranty | |
| Parts and labor | Limited 2 Years Parts & Labor |
